EL Back-lighting Switch

Material: PET/PC /Acrylic adhesive (MacDermid Autotype/SABIC/3M/Nitto)
Size/ Thickness: Customized Size/ Thickness Accepted
Flexible Or Rigid: Yes
Certification: ISO9001:2015 /ROHS/SGS

EL back-lighting switch

EL Panels have proved to be versatile and have many uses from backlighting displays, Human interface device. EL panel is a updated and safe light resource It’s the perfect solution to bring animation and attention to any indicator.


The technique of EL Panel is the glowing paint (or ‘phosphor’) that printing onto a thin polyester sheet, the such material is printed between two conductive electrodes. When give the power to the EL panel, then phosphor glow and you will see the lighting.


Our EL panels can be design as thinner that to be 0.075mm thickness, and we can incorporated the such EL panel to our membrane switch inner layers, that help illumination the membrane switch. There we also have many text/patterns and colors printing with our membrane switches, and we can illumination the area where we want to very easy. The membrane switch can give great flexibility in customizing the design to your specific application.

Custom silicone rubber keypad

Brand: FD

Material: PET/PC /Acrylic adhesive (MacDermid Autotype/SABIC/3M/Nitto)

Size/ Thickness: Customized Size/ Thickness Accepted

Flexible Or Rigid: Yes

Certification: ISO9001:2015 /ROHS/SGS

Payment terms: T/T, West Union

Shipping by: UPS / FedEx / DHL / TNT or Other Ways Specified

Delivery time: 12~15 Working Days

EL Panel Performance

Working Voltage DC12V-24V/ AC100V/AC240V
Brightness 85-160CD
Operating current less than 0.25mA/cm²
Static Capacity: 0.42nf/cm²
Life Time 2.000-5.000 work hours
Working Temperature -20℃~+70℃

Comply with ROHS & REACH

The above product information is for reference only, we mostly provide customized production according to the design requirements of customers. The all raw material we choose are all meet the demand of the ROHS  and the REACH.
