Standard Membrane Switch
Standard membrane switch
A membrane switch is a user interface that utilizes circuitry printed on layers of flexible polymer film. When actuated, the membrane switch circuitry is momentarily closed and provides an electrical signal to the main circuit board. The standard membrane switch use the four-layers or the six-layers or the eight-layers construction, the function design is very simple and useful. The standard membrane switches are a reliable and cost effective user interface that can be fully customized to meet your specific needs.
Product ID card
Brand: FD
Material: PET/PC/PVC/Acrylic adhesive(MacDermid Autotype/SABIC/3M/Nitto)
Size/ Thickness: Customized Size/ Thickness Accepted
Flexible Or Rigid: Yes
Certification: ISO9001:2015 /ROHS/SGS
Payment terms: T/T, West Union
Shipping by: UPS / FedEx / DHL / TNT or Other Ways Specified
Delivery time: 12~15 Working Days
Specification
①Material:
a.Graphic overlay- F150 /F157/F200/F207/ EBG130/EBG180/EBA130/EBA180/8010-PC/8B35-PC/PC HP40S /PC HP92S/PC FR60
b.Rear adhesive-3M 9448A/3M9080A/3M 467MP/3M 468MP/3M 7952MP/3M 9471LSE/3M 9472LSE/3M 8153LSE/3M 9495LSE/3M 9469PC/3M 9469VHB/3M 9432VHB
②Size:1.0~1800.0mm*1.0~1500.0mm
③SMD: Led, resistor, metal domes
④Keys force: 5g~1000g
⑤Circuit layers: One layer/ Two layers/Three layers/Four layers
⑥Connector: ZIF contacts / Male Pin / Female 1.27mm connector / Female 2.54mm connector / Female 5.08mm connector(FCI, Nicomatic, Memcon, Chinese brand)
⑦Waterproof design: IP61/ IP62/ IP63/ IP64/ IP65/ IP66/ IP67/ IP68
⑧Total thickness: Above 0.3mm
Electrical performance
Comply with ROHS & REACH
The above product information is for reference only, we mostly provide customized production according to the design requirements of customers. The all raw material we choose are all meet the demand of the ROHS and the REACH.
